Description

Product Features Benefits

Safety & Anti-falling Measures:

Our patented anti-fall hinge design incorporates a unique process for securely connecting the chain, fixed frame, and opening sash. This innovative approach effectively prevents the risk of sash detachment, significantly enhancing the safety and reliability of outward-opening windows.



Upgraded Anti-prying Technology:

The design incorporates a clamping locking point with a bracket and back locking point, providing anti-prying protection that meets the EU RC2 safety standard.



Exclusive Hardware Mechanism:

A hardware mechanism specifically engineered for the Bucalu outward-opening window system, featuring pre-designed positioning and tooling. This design enables quick hardware assembly, enhancing efficiency and streamlining the installation process.



Continuous Corner-sealing:

Integral corner adhesive tape ensures continuous sealing, significantly enhancing the sealing performance of joint components in doors and windows.



Humanised Handle:

The systematic structure design of the screen glass guardrail takes into account mosquito prevention, safety performance, multiple protection, and high practicability. The yarn fan is designed to open inside, which is easy to clean and maintain.



Simple Frame-sash Coplanar:

When the window sash is closed, it seamlessly integrates with the frame, creating a clean and streamlined appearance while making cleaning more convenient.



Optional Full &Half Locking:

Optional full and half-locking mechanisms allow for small-angle opening, enabling micro-ventilation while reducing the risk of falling objects.



Practical Screen Window System:

The systematic structural design of the optional screen glass guardrail integrates mosquito prevention, enhanced safety, multi-layered protection, and practicality. The inward-opening screen sash allows for easy cleaning and maintenance.



Optimised Visual Effects:

The standard stainless steel high-transparency screen is available, with an optional imported high-transparency screen, providing dual choices to cater to varying preferences and requirements.



Upgraded Sealing Performance:

The three-layer sealing process, featuring adhesive tape and an anti-shrinkage clamping design for adhesive strips, significantly enhances the sealing performance of doors and windows, ensuring greater stability and durability.



Upgraded Viewing Experience:

The narrow frame design, combined with a flush indoor and outdoor frame sash, features clean, minimalist lines and a sleek, flat facade. This design enhances the aesthetic appeal while providing an exceptional viewing experience.

______________________________________________________

Performance Parameter:

• Wall thickness of main profile: 1.8mm
• Glass clamping thickness: ≤ 35mm
• Load bearing of sash: ≤ 80KG
• Maximum size of sash: width ≤ 700mm, height ≤ 1, 700mm
• Waterproof performance GB/T7106: Level 6
• Air permeability performance GB/T7106: Level 8
• Wind load resistance performance GB/T7106: up to 5,000Pa
• Acoustic performance GB/T8485: RW up to42dB
• U value rating GB/T8484: Uw up to 1.4W/mª K
