Description

Product Features Benefits

Minimalist Panoramic Design:

The 26mm ultra-narrow edging, combined with a frame embedded in the wall design, overcomes traditional frame limitations and offers an expanded field of view.

Durable Hardware System:

With a 900kg large load-bearing capacity, this design accommodates large-sized compartments, supporting heights of up to 3.5m and widths up to 4m. The pulley is positioned at the end of the sash, providing enhanced protection during construction.

Exclusive Customised Handle:

The classic design of our D-Plus series, integrated with a concealed multi-point lock and an anti-misoperation device, provides enhanced safety performance and reliability.

Exclusive Self-Developed Seal:

Specialised adhesive tape designed for insulation and heat resistance ensures enhanced thermal performance and enables smooth window operation.

Efficient Hidden Drainage:

The systematic drainage design incorporates a hidden drainage system, optimising water flow performance while maintaining the aesthetic appeal of the product.

Ultra-Long Silent Track:

Upgraded stainless steel rails enable ultra-long customisation without joints, ensuring smoother and quieter sliding operations.

Sleek Appearance:

The concealed driving system provides a minimalist and streamlined design for the door’s overall appearance.

Security Measures:

The multi-electric colour security design enhances safety and usability. In emergency situations, the system allows for indoor manual unlocking. It features an obstacle rebound mechanism that reverses operation upon encountering obstructions and an anti-pinch light curtain for added protection.

Convenient & Durable:

The remote switch system supports Mi Home interconnection and voice control for seamless operation. It includes a facial recognition feature for enhanced security and an imported drive system for reliable performance. Maintenance is simplified, as motor servicing can be conducted without disassembling the door leaf. The sash design supports a load-bearing capacity of up to 900kg, ensuring durability and adaptability for large applications.

______________________________________________________

Optional Appearance:

• Sash A
• Sash B (non-electric)
• Sash B (electric)

______________________________________________________

Performance Parameter:

• Wall thickness of main profile: 2.2mm
• Load bearing of Sash: ≤ 900Kg
• Size of sash: width, ≤ 4,000mm, height ≤ 3,500mm
• Glass damping thickness: ≤ 32mm
• Acoustic performance GB/T8485: Rw up to36dB
• Waterproof performance GB/T7106: Normal lower frame up to level 3, HDl00B up to Level 6
• Air permeability performance GB/T7106: up to Level 8
• Wind load resistance performance GB/T7106: 2 up to 5,000Pa
• U value rating GB/T8484: Uw up to2.2W/m2 K
